The H-profile shuttering system gets its name from the fact that it resembles the letter H in cross-section, has a built-in push-button magnetic system and is sealed with a welded steel channel. It is suitable for the production of prefabricated parts such as heavy walls, mezzanine walls, external walls and parapets. It is more efficient than conventional drilling and welding of side moldings, and takes up less space than magnetic boxes attached to side moldings.

Parameter

Width: 60mm
Height: 60mm, 65mm, 70mm, 85mm, 100mm
Length: 1m, 1.5m, 2m, 3m, 3.5m, 4m
Magnetic system Retaining Forces (kg): 450kg-3000kg

U60 Magnetic Formwork System height models

U60 Magnetic Formwork System length models

Product features

Operation Mode: Manual, Robot
Push button magnetic magnet: Activated by pressure above the button, released by lever.
Different sizes: Various heights and lengths available.
End face options: No chamfer, single chamfer, double chamfer
High retention force: Built-in powerful neodymium magnets
